Introduction to Laser Technology

C. Breck Hitz, James J. Ewing, Jeff Hecht

• Publisher: Wiley-IEEE Press
• Year: 2012
• Print ISBN: 9780470916209
• eBook ISBN: 9781118219485
• Edition: 4
• Topic: Technology & Engineering
• Subtopic: Electrical Engineering & Telecommunications
• Index: Technology & Engineering

The only introductory text on the market today that explains the underlying physics and engineering applicable to all lasers

Although lasers are becoming increasingly important in our high-tech environment, many of the technicians and engineers who install, operate, and maintain them have had little, if any, formal training in the field of electro-optics. This can result in less efficient usage of these important tools.

Introduction to Laser Technology, Fourth Edition provides readers with a good understanding of what a laser is and what it can and cannot do. The book explains what types of laser to use for different purposes and how a laser can be modified to improve its performance in a given application. With a unique combination of clarity and technical depth, the book explains the characteristics and important applications of commercial lasers worldwide and discusses light and optics, the fundamental elements of lasers, and laser modification.?

In addition to new chapter-end problems, the Fourth Edition includes new and expanded chapter material on:

• Material and wavelength



• Diode Laser Arrays



• Quantum-cascade lasers



• Fiber lasers



• Thin-disk and slab lasers



• Ultrafast fiber lasers



• Raman lasers



• Quasi-phase matching



• Optically pumped semiconductor lasers



Introduction to Laser Technology, Fourth Edition is an excellent book for students, technicians, engineers, and other professionals seeking a fuller, more formal introduction to the field of laser technology.

Chapter 1

An Overview of Laser Technology

The word laser is an acronym that stands for “light amplification by stimulated emission of radiation.” In a fairly unsophisticated sense, a laser is nothing more than a special flashlight. Energy goes in, usually in the form of electricity, and light comes out. But the light emitted from a laser differs from that from a flashlight, and the differences are worth discussing.

You might think that the biggest difference is that lasers are more powerful than flashlights, but this concept is more often wrong than right. True, some lasers are enormously powerful, but many are much weaker than even the smallest flashlight. So power alone is not a distinguishing characteristic of laser light.

Chapter 5 discusses the uniqueness of laser light in detail. But for now it is enough to say that there are three differences between light from a laser and light from a flashlight. First, the laser beam is much narrower than a flashlight beam. Second, the white light of a flashlight beam contains many different colors of light, whereas the beam from a laser contains only one, pure color. Third, all the light waves in a laser beam are aligned with each other, whereas the light waves from a flashlight are arranged randomly. The significance of this difference will become apparent as you read through the next several chapters about the nature of light.

Lasers come in all sizes, from tiny diode lasers small enough to fit in the eye of a needle to huge military and research lasers that fill multistory buildings. And different lasers can produce many different colors of light. As we will explain in Chapter 2, the color of light depends on the length of its waves. Listed in Table 1.1 are some of the important commercial lasers. In addition to these fixed-wavelength lasers, several important tunable lasers are discussed in Chapter 20.

Table 1.1. Some important commercial lasers

Laser	Wavelength	Average power range
Carbon dioxide	10.6 μm	Milliwatts to tens of kilowatts
Nd:YAG	1.06 μm	Milliwatts to hundreds of watts
	532 nm	Milliwatts to watts
Nd:glass	1.05 μm	Watts^1
Diodes	Visible and IR	Milliwatts to kilowatts
Argon-ion	514.5 nm	Milliwatts to tens of watts
	488.0 nm	Milliwatts to watts
Fiber	IR	Watts to kilowatts
Excimer	Ultraviolet	Watts to hundreds of watts^2

¹ Although glass lasers produce relatively low average powers, they almost always run in pulsed mode, where their peak powers can reach the gigawatt levels. Peak powers are explained at the beginning of Chapter 11.

² Excimers, like the glass lasers discussed in the note above, are pulsed lasers, capable of peak powers in the tens of megawatts.

The “light” produced by carbon dioxide lasers and neodymium lasers cannot be seen by the human eye because it is in the infrared portion of the spectrum. Red light from a ruby or helium–neon laser, and green and blue light from an argon laser, can be seen by the human eye. But the krypton-fluoride laser’s output at 248 nm is in the ultraviolet range and cannot be directly detected visually.

Table 1.1 is by no means a complete list of the types of lasers available today; indeed, a complete list would have dozens, if not hundreds, of entries. It is also incomplete in the sense that many lasers can produce more than a single, pure color. Nd:YAG lasers, for example, are best known for their strong line at 1.06 μm, but these lasers can also lase at perhaps a dozen other wavelengths. Or, with the aid of nonlinear optics, Nd:YAG lasers can produce wavelengths in the visible, such as the green line of laser pointers, and even in the ultraviolet. Diode lasers produce beams throughout the infrared spectrum and in the short- and long-wavelength regions of the visible spectrum.

The yttrium–aluminum–garnet (YAG) and glass lasers listed are solid-state lasers. The light is generated in a solid, crystalline rod that looks much like a cocktail swizzlestick. The ytterbium-doped fiber laser is also a solid-state laser, but the solid is a thin glass fiber. Diode lasers are also solid-state devices, but through the fickleness of human terminology, the term “solid-state laser” is usually understood to include lasers such as Nd:YAG and glass, but not diode lasers. Diode lasers are based on semiconductors, and in many ways resemble high-powered light-emitting diodes.

All the other lasers listed are gas lasers that generate light in a gaseous medium, in some ways like a neon sign. If there are solid-state lasers and gaseous lasers, it is logical to ask if there is such a thing as a liquid laser. The answer is yes. The most common example is the organic dye laser, in which dye dissolved in a liquid produces the laser light.

1.1 WHAT ARE LASERS USED FOR?

We have seen that lasers usually do not produce a lot of power. By comparison, an ordinary 1200 W electric hair dryer is more powerful than 99% of the lasers in the world today. And we have seen that some types of lasers do not even produce power very efficiently, often wasting at least 99% of the electricity they consume.* So what is all the excitement about? What makes lasers so special, and what are they really used for?

The unique characteristics of laser light are what make lasers so special. The capability to produce a narrow beam does not sound very exciting, but it is the critical factor in most laser applications. Because a laser beam is so narrow, it can read the minute, encoded information on a CD or DVD, or on the bar-code patterns in a grocery store. Because a laser beam is so narrow, the comparatively modest power of a 200 W carbon-dioxide laser can be focused to an intensity that can cut or weld metal. Because a laser beam is so narrow, it can create tiny and wonderfully precise patterns in a laser printer.

The other characteristics of laser light—its spectral purity and the way its waves are aligned—are also important for some applications. And, strictly speaking, the narrow beam could not exist if the light did not also have the other two characteristics. But from a simple-minded, applications-oriented viewpoint, a laser can often be thought of as nothing more than a flashlight that produces a very narrow beam of light.

One of the leading laser applications is materials processing, in which lasers cut, drill, weld, heat-treat, and otherwise alter both metals and nonmetals. Lasers can drill tiny holes in turbine blades more quickly and less expensively than mechanical drills. Lasers have several advantages over conventional techniques of cutting materials. For one thing, unlike saw blades or knife blades, lasers never get dull. For another, lasers make cuts with better edge quality than most mechanical cutters. The edges of metal parts cut by lasers rarely need be filed or polished because the laser makes such a clean cut.

Laser welding can often be more precise and less expensive than conventional welding. Moreover, laser welding is more compatible with robotics, and several large machine-tool builders offer fully automated laser-welding systems to manufacturers.

Laser heat-treating involves heating a metal part with laser light, increasing its temperature to the point where its crystal structure changes. It is often possible to harden the surface in this manner, making it more resistant to wear. Heat-treating requires some of the most powerful industrial lasers, and it is one application in which the raw power of the laser is probably more important than the narrow beam.

Have you purchased a quart of milk or anything else with a “Use by” date on it recently? Odds are, that date was put there with a laser. Laser marking is the largest market for materials-processing lasers, in terms of the number of lasers sold.

1.2 LASERS IN TELECOMMUNICATIONS

One of the more exciting applications of lasers is in the field of telecommunications, in which tiny diode lasers generate the optical signal transmitted through optical fibers. Because the bandwidth of these fiber-optic systems is so much greater than that of conventional copper wires, fiber optics is playing a major role in enabling the fast-growing Internet.

Many modern fiber-optic telecommunication systems transmit multiple wavelengths through a single fiber, a technique called wavelength-division multiplexing. The evolution of this technology, together with erbium-doped fiber amplifiers to boost the signal at strategic points along the transmission line, is a major driving force in today’s optoelectronics market.

Any time you pick up a telephone or connect to the Internet, it is likely that, somewhere along the line, you are transmitting information across a fiber-optic link. But today, optical technology is starting to transmit data over much smaller distances, even from one point to another inside your computer. As electronic devices—computers, phones, and readers—get smaller and smaller, eventually they run into a roadblock. Because electrons push each other around (repel each other, actually), there is a limit on how close together they can be. One beam of light, however, exerts no force on another beam. Hence, transmitting information with light instead of electrons avoids the roadblock to further miniaturization.

1.3 LASERS IN RESEARCH AND MEDICINE

Lasers started out in research laboratories, and many of the most sophisticated ones are still being used there. Chemists, biologists, spectroscopists, and other scientists count lasers among the most powerful investigational tools of modern science. Again, the laser’s narrow beam is valuable, but in the laboratory the other characteristics of laser light are often important too. Because a laser’s beam contains light of such pure color, it can probe the dynamics of a chemical reaction while it happens or it can even stimulate a reaction to happen.

In medicine, the laser’s narrow beam has proven a powerful tool for therapy. In particular, the carbon dioxide laser has been widely adopted by surgeons as a bloodless scalpel because the beam cauterizes an incision even as it is made. Indeed, some surgeries that cause profuse bl...

Table of contents

• Cover
• Half Title page
• Title page
• Copyright page
• Preface
• Acknowledgments
• Chapter 1: An Overview of Laser Technology
• Chapter 2: The Nature of Light
• Chapter 3: Refractive Index, Polarization, and Brightness
• Chapter 4: Interference
• Chapter 5: Laser Light
• Chapter 6: Atoms, Molecules, and Energy Levels
• Chapter 7: Energy Distributions and Laser Action
• Chapter 8: Laser Resonators
• Chapter 9: Resonator Modes
• Chapter 10: Reducing Laser Bandwidth
• Chapter 11: Q-Switching
• Chapter 12: Cavity Dumping and Modelocking
• Chapter 13: Nonlinear Optics
• Chapter 14: Semiconductor Lasers
• Chapter 15: Solid-State Lasers
• Chapter 16: Fiber Lasers
• Chapter 17: Gas Lasers: Helium–Neon and Ion
• Chapter 18: Carbon Dioxide and Other Vibrational Lasers
• Chapter 19: Excimer Lasers
• Chapter 20: Tunable and Ultrafast Lasers
• Glossary
• Further Reading
• Index
