Hydrogen Storage Technologies

New Materials, Transport, and Infrastructure

Agata Godula-Jopek, Walter Jehle, Joerg Wellnitz

• Publisher: Wiley-VCH
• Year: 2012
• Print ISBN:
  9783527326839
• eBook ISBN:
  9783527649945
• Edition: 1
• Topic: Physical Sciences
• Subtopic: Industrial & Technical Chemistry

An exploration of current and possible future hydrogen storage technologies, written from an industrial perspective. The book describes the fundamentals, taking into consideration environmental, economic and safety aspects, as well as presenting infrastructure requirements, with a special focus on hydrogen applications in production, transportation, military, stationary and mobile storage.

A comparison of the different storage technologies is also included, ranging from storage of pure hydrogen in different states, via chemical
storage right up to new materials already under development. Throughout, emphasis is placed on those technologies with the potential
for commercialization.

Chapter 1

Introduction

1.1 History/Background

Storage of hydrogen is still one of the key issues of the usage of hydrogen itself for vehicle transportation. Main activities on these fields were recorded in the early times of space flight, whereas launching-systems/liquid propelled systems were driven by hydrogen and oxygen fuel.

The development of lightweight tank systems played – from the beginning – a very important role [1], as well as the adjusted issues of pipes, hoses, and dressings.

In Figure 1.1 a typical setup of a pressurized hydrogen or oxygen tank is given, designed with a filament winding method from the early 1950s and 1960s of the last century.

Figure 1.1 H2 and O2 tanks manufactured with filament winding technique in Lockheed–Martin laboratories.

From these issues the storage of hydrogen can be mainly divided into two major technology approaches:

• Pressure storage, CH2, using high pressurized H2 in special tank systems in order to store an amount of n-kg of mass for the use in vehicles.
• Liquid storage, LH2, where the gaseous agent is liquefied below 50 K with moderate pressure (less than 10 bar) and held in a thermo-insulated tank setup.

In this chapter the emphasis will lie on the background of pressurized storage of hydrogen with a special focus on ground transportation, automotive, and tracking.

In Figure 1.2 the basic storage capacities of LH2 and CH2 are given with respect to cost and manufacturability margins.

Figure 1.2 CH2 and LH2 storage outlines with respect to design, cost, and weight margins.

The early developments of hydrogen tanks are closely linked with space flight programs such as Mercury, Gemini, Delta, and the Apollo program, only to mention NASA projects.

The demands of space flights as a part of early application in transportation are very high, on the other hand cost and manufacturing issues played a minor role in this field of application. Due to technical boundary conditions, mainly cylinder- or elliptical-cylinder-tanks were designed which were the best fit for the fuselage of launchers. This layout was mainly driven by static determinations of the current limited ultimate load-cases where the burst and rupture strength of the structure were taken into account for layout. In addition to that, dressing systems were mainly driving the weight-penalty of the structure, by demanding special in- and out-design-features as an interface to composite materials.

Figure 1.3 explains the problem field of interfaces and connectors between dressing-systems and the homogeneous and monolithic tank structure.

Figure 1.3 Problem field of interconnection between dressings and the monolithic composite.

The usage of tank systems for ground transportation or vehicles had already been introduced in the early 19th century within the use of hydrogen carriages. Figure 1.4 shows the earliest hydrogen application ever recorded on a carriage system by De Rivaz from 1808.

Figure 1.4 The earliest application of hydrogen in a ground transportation vehicle – carriage – the earliest predecessor of cars.

The development of tank systems for automotive application in the second half of the last century was mainly driven by BMW automotive tank systems, which were using internal combustion engines (ICEs) as the main propulsion system (Figure 1.5). This project, among other parallel developments such as Ford, Man, Mazda, see [2], was one of the main drivers of hydrogen storage, as well as this, BMW has decided to use the storage system LH2 from the very beginning in order to carry more kilograms of hydrogen and therefore to extend the range.

Figure 1.5 Tank system with the use of CH2 for PSA automotive application using a cylindrical tank rack system in a conventional passenger car.

The recent projects founded by the European government – mainly StorHy (2004–2008) – were focused on the cost critical and production critical issues of the storage of hydrogen and have also lined out major criteria for a practical use of hydrogen in passenger car vehicles.

In [3], a brief overlook at the results of the StorHy project is given, the main aspects of the developments of this project are also used by the authors as an input for future strategies of hydrogen storage.

1.2 Tanks and Storage

The storage of a gaseous agent in tank systems under pressure or high pressure can be linked to the conventional task of layout of pressurized vessels in engineering mechanics.

Mainly the gas, as the fuel for the propulsion system, will be put under high pressure and stored in mostly rotationally symmetric tank systems. The pressure especially for hydrogen will vary between 100 and 750 bar, in particular driven by the demand of the vehicle. This pressure range allows between 0.5 and 3 kg of H2 to be carried. Figure 1.6 shows a conventional tank system by the manufacturer Dynetek with the daily operational pressure of 350 bar and the burst pressure of about 1000 bar.

Figure 1.6 Conventional CH2 pressurized tank system for automotive usage at 350 bar.

This tank is designed with an aluminum liner on the inside to avoid critical H2 permeation and a filament winded carbon fiber hull is used to cope with the high circumferential stresses.

With a storage mass of about 1 kg of hydrogen a typical range of about 100 km can be reached using an internal combustion engine (ICE) and about 150 km on conventional fuel cell applications (F/C). This would automatically demand a typical required mass of at least 3 kg hydrogen for a passenger car, in order to establish practical useful ranges for the customer.

Pressurized gas in tank systems will lead to high circumferential normal stresses, which can be calculated using the pressure-vessel theory. Pressure vessels based on a rotationally symmetric topology can be calculated with the so-called half membrane theory, which will include the membrane stress state and a set of transfer forces for the static equilibrium balance. The normal forces and the shear stresses can be calculated as a function of the metric of the tank system with the conventional orthotropic shell theory [4].

In Figure 1.7 the stresses are shown as a function of the cutting reactional forces of the shell under internal pressure load.

Figure 1.7 Cutting reactional forces of a shell element under internal pressure.

With the help of the statical determination by balancing all forces and moments, the main stresses of the vessel under internal pressure load can be calculated. The investigatio...

Table of contents

• Cover
• Contents
• Title
• Copyright
• Preface
• Chapter 1: Introduction
• Chapter 2: Hydrogen – Fundamentals
• Chapter 3: Hydrogen Application: Infrastructural Requirements
• Chapter 4: Storage of Pure Hydrogen in Different States
• Chapter 5: Chemical Storage
• Chapter 6: Hydrogen Storage Options: Comparison
• Chapter 7: Novel Materials
• Index
