Lens Maker Equation

9 Key excerpts on "Lens Maker Equation"

•

  eBook - PDF

  Microlenses

  Properties, Fabrication and Liquid Lenses

  • Hongrui Jiang, Xuefeng Zeng(Authors)
  • 2016(Publication Date)
  • CRC Press

    (Publisher)

  16 Microlenses: Properties, Fabrication and Liquid Lenses © 2008 Taylor & Francis Group, LLC Equations (2.7) and (2.8) are then substituted into Snell’s law, sin sin α β = n n 2 1 (2.9) to obtain n o n i n n R n R 1 2 2 1 + = -= ∆ (2.10) which is Gauss’ formula for refraction at a single refracting surface. Here Δ n is the difference between the refractive index of the material of the lens and that of the outside medium, and R is the radius of curvature of the surface. The refractive power of a surface is defined as the ratio of the refractive index of the medium over the focal length, as expressed in Equation (2.11). A surface or lens of short focal length has high refractive power, and vice versa. P n f n R = = ∆ (2.11) 2.2.3 Thin Lenses A lens is defined as thin if a ray entering on one surface emerges at approxi-mately the same position on the opposite surface; that is, negligible transla-tion occurs in the lens. However, there is no numerical limit distinguishing thin and thick lenses. The issue is decided entirely by the degree of precision required for solving a given problem. One lens may be considered thin for a preliminary and thick for a rigorous solution. A thin lens can be considered the sum of two single refractive surfaces: FIGURE 2.3 Refraction at single spherical surface. 17 Basic Physics of Liquid Microlenses © 2008 Taylor & Francis Group, LLC P P P n R n R = + = + 1 2 1 2 ∆ ∆ (2.12) P f n R R = = +       1 1 1 1 2 ∆ (2.13) Their powers added together represent the lens maker’s formula. Note that in Equation (2.13), n is assumed to be 1. 2.2.4 Aberrations 2.2.4.1 Spherical Aberration Spherical aberration arises when rays passing through different zones of a lens come to different focal points. In general, rays close to the optic axis are refracted less and come to a focus further away from the lens than the marginal rays, as shown in Figure 2.4.

  Sign up to read

  Learn more about book
•

  eBook - PDF

  Physics, Student Study Guide

  • John D. Cutnell, Kenneth W. Johnson, David Young, Shane Stadler(Authors)
  • 2018(Publication Date)
  • Wiley

    (Publisher)

  It produces a final image which is inverted and virtual. Spherical aberration An effect in which rays from the outer edge of a spherical lens are not focused at the same point as rays that pass through the center of the lens, thus causing images to be blurred. Chromatic aberration An undesirable lens effect arising when a lens focuses different colors at different points. Equations The index of refraction of a material is _ Speed oflight in a vacuum _ c n- -- Speed of light in the material v (26.1) Snell's law of refraction (26.2) 338 THE REFRACTION OF LIGHT: LENSES AND OPTICAL INSTRUMENTS The apparent depth of an object with the observer directly above the object is (26.3) The critical angle for total internal reflection is given by (26.4) Brewster's Law (26.5) The thin-lens equation (26.6) The magnification equation _ Image height _ hi _ di m- ----- Object height ho d 0 (26. 7) The refractive power of a lens is given by: Refractive power (in diopters) = 1 f(in meters) (26.8) The angular magnification of an optical instrument is: M = Angular size produced by instrument = .!t_ Reference angular size 9 (26.9) The angular magnification of a magnifying glass is: (26.10) The angular magnification of a compound microscope is given by: (26.11) Chapter 26 339 The angular magnification of an astronomical telescope is: (26.12) DISCUSSION OF SELECTED SECTIONS 26.2 Snell"s Law and the Refraction of Light When light travels across an interface from one medium to another, it undergoes a change in its speed as indicated by the different indices of refraction of the materials. This speed change results in a bending (refraction) of the path of the light unless it strikes the interface at normal incidence (See figure 26.2 in the text.). Snell's law (equation 26.2) can be used to calculate the amount of bending. Example 1 Light strikes an interface between two materials of refractive indices, n1 and n2, at an angle el to the normal to the surface.

  Sign up to read

  Learn more about book
•

  eBook - ePub

  Applied Optics and Optical Design, Part One

  • A. E. Conrady(Author)
  • 2013(Publication Date)
  • Dover Publications

    (Publisher)

  The exact ray-tracing formulae with which we have dealt up to now find their chief application in the later stages of the evolution of new optical designs. A very large amount of practically useless labour would be required if we attempted to test every rough preliminary scheme by these formulae and thus to feel our way, largely in a more or less blindfold manner, to the finished instrument. Progress towards the ultimate perfection will be quickest if we begin with a rough first approximation and gradually apply more refined methods as the work proceeds. In the majority of cases we can arrive at such a simple scheme most quickly and with very little trouble by determining what combination of thin simple lenses would produce the intended effect. Therefore we must now deduce suitable formulae which enable us to calculate the properties of simple lenses.

  Equation (6p)** can be applied to the two surfaces of a simple lens so as to yield a single expression for its focal effects.

  Referring to Fig. 18 , we shall have by the transfer-equations (5p)* and , therefore for the first surface

  for the second surface

  If the first equation is multiplied throughout by the stated factor its left side becomes equal to the last term on the right of the second equation ; these two terms therefore cancel each other when the second equation is added to the extended first, with the result

  Taken together with the equation for the first surface, this is the most general, but decidedly inconvenient, solution of the problem of a thick lens. The equation becomes simpler if we assume that , that is, that the lens is employed immersed in a medium of index N 1 . We then have

  or on division throughout by N 1

  Here is the relative refractive index of the material of the lens referred to the surrounding medium and using the simple symbol N for this index, we find the solution

  (IIP)

  in which

  The second equation following on dividing the original equation of the first surface by N 1 and introducing

  FIG. 18 .

  The equation will be almost exclusively applied to lenses used in air, and N will then be the ordinary refractive index of the glass. But it should be remembered that the equation can be applied to a lens which, together with its object and image, is immersed in a medium other than air, provided that N is then taken as the relative index of the glass to the medium.

  (IIp) is an exact paraxial equation : it will be modified on a subsequent occasion so as to render it a useful solution of the problem of a thick lens. For the present we merely use it as a means to deduce the simplest possible equations for use in rough and rapid preliminary studies of lenses and lens systems by restricting the equations to very thin lenses in which may be treated as negligible in comparison to . The inconvenient factor in (IIp) then becomes = 1, but as this would be strictly correct only for an infinitely thin lens, we must note once for all that the convenient equations obtained on this assumption are (with certain rare exceptions) only a more or less rough approximation when applied to actual lenses, and too much dependence must not be placed on the results obtained by them. As a constant reminder of the inaccuracy of these equations we will distinguish them by putting TL (= thin lens) in front of the numbers assigned to them. The fundamental equation is found by omitting the factor
