Smart Grid

Technology and Applications

Janaka B. Ekanayake, Nick Jenkins, Kithsiri Liyanage, Jianzhong Wu, Akihiko Yokoyama

• Publisher: Wiley
• Year: 2012
• Print ISBN: 9780470974094
• eBook ISBN: 9781119969099
• Edition: 1
• Topic: Technology & Engineering
• Subtopic: Power Resources
• Index: Technology & Engineering

Electric power systems worldwide face radical transformation with the need to decarbonise electricity supply, replace ageing assets and harness new information and communication technologies (ICT). The Smart Grid uses advanced ICT to control next generation power systems reliably and efficiently. This authoritative guide demonstrates the importance of the Smart Grid and shows how ICT will extend beyond transmission voltages to distribution networks and customer-level operation through Smart Meters and Smart Homes.

Smart Grid Technology and Applications:

• Clearly unravels the evolving Smart Grid concept with extensive illustrations and practical examples.
• Describes the spectrum of key enabling technologies required for the realisation of the Smart Grid with worked examples to illustrate the applications.
• Enables readers to engage with the immediate development of the power system and take part in the debate over the future Smart Grid.
• Introduces the constituent topics from first principles, assuming only a basic knowledge of mathematics, circuits and power systems.
• Brings together the expertise of a highly experienced and international author team from the UK, Sri Lanka, China and Japan.

Electrical, electronics and computer engineering researchers, practitioners and consultants working in inter-disciplinary Smart Grid RD&D will significantly enhance their knowledge through this reference. The tutorial style will greatly benefit final year undergraduate and master's students as the curriculum increasing focuses on the breadth of technologies that contribute to Smart Grid realisation.

1

The Smart Grid

1.1 Introduction

Established electric power systems, which have developed over the past 70 years, feed electrical power from large central generators up through generator transformers to a high voltage interconnected network, known as the transmission grid. Each individual generator unit, whether powered by hydropower, nuclear power or fossil fuelled, is large with a rating of up to 1000 MW. The transmission grid is used to transport the electrical power, sometimes over considerable distances, and this power is then extracted and passed through a series of distribution transformers to final circuits for delivery to the end customers.

The part of the power system supplying energy (the large generating units and the transmission grid) has good communication links to ensure its effective operation, to enable market transactions, to maintain the security of the system, and to facilitate the integrated operation of the generators and the transmission circuits. This part of the power system has some automatic control systems though these may be limited to local, discrete functions to ensure predictable behaviour by the generators and the transmission network during major disturbances.

The distribution system, feeding load, is very extensive but is almost entirely passive with little communication and only limited local controls. Other than for the very largest loads (for example, in a steelworks or in aluminium smelters), there is no real-time monitoring of either the voltage being offered to a load or the current being drawn by it. There is very little interaction between the loads and the power system other than the supply of load energy whenever it is demanded.

The present revolution in communication systems, particularly stimulated by the internet, offers the possibility of much greater monitoring and control throughout the power system and hence more effective, flexible and lower cost operation. The Smart Grid is an opportunity to use new ICTs (Information and Communication Technologies) to revolutionise the electrical power system. However, due to the huge size of the power system and the scale of investment that has been made in it over the years, any significant change will be expensive and requires careful justification.

The consensus among climate scientists is clear that man-made greenhouse gases are leading to dangerous climate change. Hence ways of using energy more effectively and generating electricity without the production of CO2 must be found. The effective management of loads and reduction of losses and wasted energy needs accurate information while the use of large amounts of renewable generation requires the integration of the load in the operation of the power system in order to help balance supply and demand. Smart meters are an important element of the Smart Grid as they can provide information about the loads and hence the power flows throughout the network. Once all the parts of the power system are monitored, its state becomes observable and many possibilities for control emerge.

In the UK, the anticipated future de-carbonised electrical power system is likely to rely on generation from a combination of renewables, nuclear generators and fossil-fuelled plants with carbon capture and storage. This combination of generation is difficult to manage as it consists of variable renewable generation and large nuclear and fossil generators with carbon capture and storage that, for technical and commercial reasons, will run mainly at constant output. It is hard to see how such a power system can be operated cost-effectively without the monitoring and control provided by a Smart Grid.

1.2 Why implement the Smart Grid now?

Since about 2005, there has been increasing interest in the Smart Grid. The recognition that ICT offers significant opportunities to modernise the operation of the electrical networks has coincided with an understanding that the power sector can only be de-carbonised at a realistic cost if it is monitored and controlled effectively. In addition, a number of more detailed reasons have now coincided to stimulate interest in the Smart Grid.

1.2.1 Ageing assets and lack of circuit capacity

In many parts of the world (for example, the USA and most countries in Europe), the power system expanded rapidly from the 1950s and the transmission and distribution equipment that was installed then is now beyond its design life and in need of replacement. The capital costs of like-for-like replacement will be very high and it is even questionable if the required power equipment manufacturing capacity and the skilled staff are now available. The need to refurbish the transmission and distribution circuits is an obvious opportunity to innovate with new designs and operating practices.

In many countries the overhead line circuits, needed to meet load growth or to connect renewable generation, have been delayed for up to 10 years due to difficulties in obtaining rights-of-way and environmental permits. Therefore some of the existing power transmission and distribution lines are operating near their capacity and some renewable generation cannot be connected. This calls for more intelligent methods of increasing the power transfer capacity of circuits dynamically and rerouting the power flows through less loaded circuits.

1.2.2 Thermal constraints

Thermal constraints in existing transmission and distribution lines and equipment are the ultimate limit of their power transfer capability. When power equipment carries current in excess of its thermal rating, it becomes over-heated and its insulation deteriorates rapidly. This leads to a reduction in the life of the equipment and an increasing incidence of faults. If an overhead line passes too much current, the conductor lengthens, the sag of the catenary increases, and the clearance to the ground is reduced. Any reduction in the clearance of an overhead line to the ground has important consequences both for an increase in the number of faults but also as a danger to public safety. Thermal constraints depend on environmental conditions, that change through the year. Hence the use of dynamic ratings can increase circuit capacity at times.

1.2.3 Operational constraints

Any power system operates within prescribed voltage and frequency limits. If the voltage exceeds its upper limit, the insulation of components of the power system and consumer equipment may be damaged, leading to short-circuit faults. Too low a voltage may cause malfunctions of customer equipment and lead to excess current and tripping of some lines and generators. The capacity of many traditional distribution circuits is limited by the variations in voltage that occur between times of maximum and minimum load and so the circuits are not loaded near to their thermal limits. Although reduced loading of the circuits leads to low losses, it requires greater capital investment.

Since about 1990, there has been a revival of interest in connecting generation to the distribution network. This distributed generation can cause over-voltages at times of light load, thus requiring the coordinated operation of the local generation, on-load tap changers and other equipment used to control voltage in distribution circuits. The frequency of the power system is governed by the second-by-second balance of generation and demand. Any imbalance is reflected as a deviation in the frequency from 50 or 60 Hz or excessive flows in the tie lines between the control regions of very large power systems. System operators maintain the frequency within strict limits and when it varies, response and reserve services are called upon to bring the frequency back within its operating limits [1]. Under emergency conditions some loads are disconnected to maintain the stability of the system.

Renewable energy generation (for example. wind power, solar PV power) has a varying output which cannot be predicted with certainty hours ahead. A large central fossil-fuelled generator may require 6 hours to start up from cold. Some generators on the system (for example, a large nuclear plant) may operate at a constant output for either technical or commercial reasons. Thus maintaining the supply–demand balance and the system frequency within limits becomes difficult. Part-loaded generation ‘spinning reserve’ or energy storage can address this problem but with a consequent increase in cost. Therefore, power system operators increasingly are seeking frequency response and reserve services from the load demand. It is thought that in future the electrification of domestic heating loads (to reduce emissions of CO2) and electric vehicle charging will lead to a greater capacity of flexible loads. This would help maintain network stability, reduce the requirement for reserve power from part-loaded generators and the need for network reinforcement.

1.2.4 Security of supply

Modern society requires an increasingly reliable electricity supply as more and more critical l...
