Clutches

8 Key excerpts on "Clutches"

•

  eBook - PDF

  Mechanical Design

  • P.R.N. Childs, T.H.C. Childs(Authors)
  • 2003(Publication Date)
  • Butterworth-Heinemann

    (Publisher)

  10.2 Clutches The function of a clutch is to permit the connec-tion and disconnection of two shafts, either when both are stationary or when there is a difference in the relative rotational speeds of the shafts. Clutch connection can be achieved by a number of tech-niques from direct mechanical friction, electro-magnetic coupling, hydraulic or pneumatic means or by some combination.There are various types of Clutches as outlined in Figure 10.3.The devices considered here are of the friction type. Clutches must be designed principally to sat-isfy four requirements: 1. The necessary actuation force should not be excessive. 2. The coefficient of friction should be constant. 3. The energy converted to heat must be dissi-pated. 4. Wear must be limited to provide reasonable clutch life. Alternatively the objective in clutch design can be stated as maximization of a maintainable friction coefficient and minimization of wear. Correct clutch design and selection are critical because a clutch that is too small for an applica-tion will slip and overheat and a clutch that is too large will have a high inertia and may overload the drive. Positive contact Clutches have teeth or serrations, which provide mechanical interference between mating components. Figure 10.4 shows a square jaw and Figure 10.5 shows a multiple serration posi-tive contact clutch. This principle can be com-bined with frictional surfaces as in an automotive Chapter 10 195 synchromesh clutch. As helical gears cannot be shifted in and out of mesh easily, the pragmatic approach is to keep the gears engaged in mesh and allow the gear to rotate freely on the shaft when no power is required but provide positive location of the gear on the shaft when necessary (see also Chapter 6, Section 6.3.1). Friction Clutches consist of two surfaces, or two sets of surfaces, which can be forced into frictional contact.A frictional clutch allows gradual engage-ment between two shafts.

  Sign up to read

  Learn more about book
•

  eBook - PDF

  Mechanotechnics N6 Student's Book

  TVET FIRST

  • Sparrow Consulting(Author)
  • 2021(Publication Date)
  • Macmillan

    (Publisher)

  The result is the ability to start and stop the driven shaft without impacting the driving shaft. Clutches are also used to control the transmission of power or motion in amount or over time. In Figure 1.2, the clutch transmits the engine’s power to the transmission for the vehicle to pull away and during driving (a). It disconnects the engine power when stopping the vehicle or changing gears (b). Figure 1.2: Engaged and disengaged clutch in a vehicle (a) When pulling away and driving (b) During gear changes and stopping power: the ability to supply a machine with a form of energy coaxial: having a common axis torque: rotating force 3 Clutches TVET FIRST A clutch consists of four main components (see Figure 1.1): • Flywheel. • Clutch plate. • Pressure plate. • Release bearing. The flywheel is mounted on the engine shaft. It is the driving member of the clutch. The pressure plate is bolted to the flywheel, and they rotate together. The pressure plate acts as a spring-loaded clamp and clamps the clutch plate to the flywheel. The release bearing is behind the pressure plate. It can move axially along the driven shaft or transmission shaft of the vehicle. It is used to load the spring, which causes the clamping action of the pressure plate. The clutch plate or friction plate is located between the flywheel and pressure plate. The clutch plate is mounted on a guide that moves along splines cut into the input shaft. flywheel clutch cover diaphragm spring release bearing clutch plate pressure plate clutch fork Figure 1.3: Clutch components The clutch pedal is connected to the clutch fork with a clutch cable or hydraulic system (see Figure 1.3). This causes the fork to pivot. The clutch fork is attached to the release bearing. It controls its direction of motion along the shaft. To engage the clutch: • The release bearing applies an axial force to a coil spring or diaphragm spring in the clutch cover. This pushes the pressure plate onto the clutch plate.

  Sign up to read

  Learn more about book
•

  eBook - PDF

  Fundamentals of Machine Design: Volume 2

  • Ajeet Singh(Author)
  • 2017(Publication Date)
  • Cambridge University Press

    (Publisher)

  Outcomes Learn definition, function, and types of Clutches Difference between positive drive and friction clutch Friction materials and their coefficient of friction Variation of bearing pressure with radius Torque transmission capacity with uniform pressure and uniform wear theories Maximum torque transmission capacity Design of single plate clutch Time for clutch engagement Heat generated during clutching Multi-plate and cone Clutches Design of a cone clutch Centrifugal clutch; its construction, working, and design 18.1 Definition and Function A clutch is a device, which can be used to connect or disconnect the incoming power from a driver shaft to a driven shaft at same speed or less than driver speed, whenever desired without stopping the driver shaft. It is used invariably in an automobile, shown in picture on right side, where engine rotates continuously, while the wheels rotate at reduced speeds from zero to maximum. The power comes from C H A P T E R 18 Clutches Fundamentals of Machine Design, Volume II 682 engine to clutch at speed N . Speed after the clutch can have any value between zero to N and then to gear box to allow different speed to get high torque at starting as shown pin Figure 18.1. In top gear, there is no reduction. Universal couplings help in transferring power at any angle. A permanent reduction of about 4–5 is provided in differential, to further reduce the speed of the propeller shaft and transfer power at right angles to the wheels. Engine Clutch Gear Box Universal coupling Propeller shaft Differential Axle Wheel Universal coupling Wheel Axle N N Figure 18.1 Location of a clutch in an automobile Main functions of a clutch are: • Connect or disconnect the power from a driver shaft to the driven shaft. The shafts should be collinear, that is, their axes should be in one straight line, otherwise its performance deteriorates. • Provide any speed between zero to maximum of the driver shaft speed.

  Sign up to read

  Learn more about book
•

  eBook - ePub

  Mechanical Design Engineering Handbook

  • Peter Childs, Peter R. N. Childs(Authors)
  • 2013(Publication Date)
  • Butterworth-Heinemann

    (Publisher)

  Chapter 13

  Clutches and Brakes

  Abstract

  A clutch is a device that permits the smooth, gradual connection of two shafts rotating at different speeds. A brake enables the controlled dissipation of energy to slow down, stop, or control the speed of a system. This chapter describes the basic principles of frictional Clutches and brakes and outlines design and selection procedures for disc Clutches as well as disc and drum brakes.

  Keywords

  Band; Brake; Clutch; Design; Disc; Drum; Friction; Long; Multiple; Power; Shoe; Short; Transmission

  Chapter Outline

  13.1 Introduction 13.2 Clutches 13.2.1 Design of Disc Clutches 13.3 Brakes 13.3.1 Disc Brakes 13.3.2 Drum Brakes 13.3.3 Short-Shoe External Drum Brakes 13.3.4 Long-Shoe External Drum Brakes 13.3.5 Long-Shoe Internal Drum Brakes 13.3.6 Band Brakes 13.4 Conclusions References Further Reading Nomenclature

  13.1 Introduction

  When a rotating machine is started it must be accelerated from rest to the desired speed. A clutch is a device used to connect or disconnect a driven component from a prime mover such as an engine or motor. A familiar application is the use of a clutch between an engine's crankshaft and the gearbox in automotive settings. The need for the clutch arises from the relatively high torque requirement to get a vehicle moving and the low torque output from an internal combustion engine at low levels of rotational speed. The disconnection of the engine from the drive enables the engine to speed up unloaded to about 1000 rpm, where it generates sufficient torque to drive the transmission. The clutch can then be engaged, allowing power to be transmitted to the gearbox, transmission shafts, and wheels. A brake is a device used to reduce or control the speed of a system or bring it to rest. Typical applications of a clutch and brake are illustrated in Figure 13.1
